HP-IPD240  240W Series Din-Rail Industrial Power Supply
+
  • HP-IPD240  240W Series Din-Rail Industrial Power Supply

Applied to rail transit, expressway, power station, pipe gallery project and wireless wiring project

Category:

Key words: switch

Messages
  • Describe
  • Specifications
  • Application
  • Order Information
  • Documentation
  • Download
  • Product Description:
    HP-IPD240 is a 240W industrial din rail power supply which is independently developed by Shenzhen Hynapower Technology Co., Ltd. This power supply width is 40.5mm, suitable for installation on TS-35/or TS-35/15 rails, 90Vac to 260Vac full voltage range AC input, 24V, 48V DC output, comply with EN61000-3-2 standard.
    IDP240 is aluminum alloy shell, this could improve the heat dissipation effect of the whole power supply.  Efficiency is as high as 93% or more. Under air circulation conditions, the entire series can work at an ambient temperature of -40℃ to +70℃, perfect solutions for industrial area power supply applications.

    Product Features:
        Input:90〜260VAC
        Output: 24V, 48V(optional)
        Output max power:240W
        Universal input voltage
        short-circuit/overload, over-voltage/over-temperature protection
        High reliability, high efficiency, LEVEL VI
        Natural cool
        100% full load aging test
        UL508 (Industrial Control Equipment)
        N61000-6-2 (EN50082-2) industrial immunity
        AC input lightning protection 6KVA
        Work temperature:-40〜70℃(Please refer to "Derating Curve")
        IP30 aluminum case
        MTBF200,000 hours
        EMI:FCC Part 15. CISPR(EN55032) class A
        EMS:EN61000-4-2(ESD),EN61000-4-3(RS)
        EN61000-4-4(EFT),EN61000-4-5(Surge)
         EN61000-4-6(CS),EN61000-4-6(Common mode conduction)
        Industrial:IEC6100-6-2
        Railway:EN50155.EN50121-4
        Transportation:NEMA TS-2
        Warranty:2years


  • Input Specification

    Item

    Technical specification

    Remark

    Input Voltage Range

    90-264Vac



    Input Frequency(Hz)

    47Hz63Hz



    Input Current

    <3.5A/110Vac

    <2A/220Vac



    Inrush Current

    20A/115Vac 35A/220Vac

    Cool Condition

    Efficiency(%)

    93%     LEVEI

    230Vac full load

    Lightning strike

    6KVA



    Power Factor(Active PFC)

    0.99/100Vac

    Full load

    Output Specification

    Model

    IDP120-24

    IDP120-48



    Output Voltage

    DC24V

    DC48V



    Output Current Range

    010A

    05A



    Voltage Accuracy

    ± 1.0%

    ± 1.0%



    Voltage Level Adjustment Range

    2428V

    4855V



    Output Power

    240W

    240W



    Line Regulation

    ± 1.0%

    ± 1.0%



    Load regulation

    ± 2%

    ± 2%



    Ripple & Noise

    <300mV

    <200mV



    Efficiency

    93% typ.

    93% typ.



    Minimum load during test

    10% of full load power

    10% of full load power



    Test conditions

    20MHz bandwidth, a 10uF electrolytic capacitor and a 0.1uF polyester capacitor are tested in parallel at  the load end.

    Safety Requirements

    Isolation Strength & Isolation Resistance



    Item

    Specification

    Isolation Strength*

     Isolation Resistance**

    Input-----Output

    3.00KVac   5ma

    100MΩ

    Input-----Ground

    2.0KVac    5ma

    100MΩ

    Output-----Ground

    0.5KVac    5ma

    100MΩ

    Remark

    *indicates the withstand voltage RatingV);Allowable maximum leakage currentmA)。**Test conditionsThe test voltage was 500VDC90%RH

    Leakage Current



    item

    Specification

    264Vac

    3.5Ma





    Operational Environment

    Item

    Specification

    Temperature



    Operating Ambient

    -40~70℃(Please refer to "Derating Curve"

    Storage Environment

    -40~85

    Humidity



    Working Humidity

    20%RH~90%RH

    Storage Humidity

    10%RH~95%RH

    Heat-dissipating Method

    Natural cool

    Atmospheric Pressure

    /

    Altitude

    Under 2000M



    Other Specifications

    MTBF

    50000 hours MIL-HDBK-217F(25)

    Size

    60*138*150mmW*H*D

    Weight

    660g ±10g

    Product installation and use instructions

    1. Do not exceed the nominal value of the power supply during use, so as not to affect the reliability of the product. If you need to change the output parameters of the power supply, please consult the technical department of our company before using the power supply to ensure the use effect  and reliability.

    2. In order to ensure the safety of use and reduce interference, please ensure that the grounding terminal is reliably grounded (the grounding wire is larger than AWG18#).

    3. Our power supply is mainly suitable for resistive loads. If you need to use capacitive or inductive loads, please communicate with our marketing department before ordering to prevent inconvenience.

    If the power supply fails, please do not repair it without authorization, please contact the quality department of our company as soon as possible.

    Packaging, transportation, storage

    1 Packaging: The packaging box has the product name, model, manufacturer's logo, manufacturer's quality department inspection certificate, manufacturing date, etc.

    2 Transportation: This packaging is suitable for transportation by cars, ships, airplanes, trains, etc., during transportation, it should be sun-proof, rain-proof, and civilized loading and unloading.

    3 Storage: The product should be placed in the packaging box when not in use. The storage environment temperature and relative humidity should meet the requirements of the product. There should be no corrosive gases or products in the warehouse, and there should be no strong mechanical vibration, shock or strong magnetic field. . The packing box should be at least 20cm high from the ground, and at least 50cm away from the wall, heat source, and window air inlet. If the storage time is too long (more than 2 years), it should be re-inspected before use.



  • Model

    HP-IDP240-24V

    240W  industrial din rail power supply24V10A output

    HP-IDP240-48V

    240W  industrial din rail power supply48V5A output
