S1608
+
  • S1608

Applied to rail transit, expressway, power station, pipe gallery project and wireless wiring project

Category:

Key words: switch

Messages
  • Describe
  • Specifications
  • Application
  • Order Information
  • Documentation
  • Download
  • The S1608, a low-cost desktop network switch, is designed by Hi-Net Technology Company. It provides 8 10/100/1000Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable.



    The S1608 is a metal-shell device which is useful for the small office and home using.



    Product Features:

    ● IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z

    ● Provides 8 10/100/1000Base-TX ports

    ● High back-plane bandwidth 16Gbps

    ● 4K MAC address table

    ● Reliable Power Adapter

    ● IEEE802.3x Flow control

    ● Surge protection for power port and data ports

    ● Plug and play, no configuration required

    ● EMI standards complies with FCC, CE class B

  • Item

    Description

    Summarize

    Fixed port

    8 10/100/1000Base-TX ports.

    LED Indicators

    PWR, Speed, Link/Act VLAN LED.

    Input voltage

    100V240V AC50/60Hz

    Network Media

    10BASE-TX: UTP category 5, 5e cable (≤250m)
    100BASE-TX: UTP category 5, 5e cable (≤150m)

    1000BASE-TX: UTP category 5, 5e cable (≤150m)

    Forwarding Rate

    10BASE-T: 14880pps/port
    100BASE-TX: 148800pps/port

    1000BASE-TX: 148800pps/port

    Power consumption

    3W

    Operating temperature

    0℃~40.

    Storage temperature

    -10℃~70.

    Relative humidity

    20%85% (non-condensing).

    Thermal methods

    Fanless.

    Switching capacity

    16G.

    MAC address table

    4K.

    Traffic control

    IEEE 802.3x full-duplex flow control.

    Size

    9.2*6.9*2.5cm

    Packing Size

    19.1*14.1*6.4cm

    Unit weight

    400g

    Package

    S1608 Network Switch

    User Manual

    Power Adapter

    Warranty Card

  • S1608

    8 ports Gigabit Network Switch
