IPX104 Industrial 10/100M PoE Extender, 1bt power input 4 at power output
+
  • IPX104 Industrial 10/100M PoE Extender, 1bt power input 4 at power output

Applied to rail transit, expressway, power station, pipe gallery project and wireless wiring project

Category:

Key words: switch

Messages
  • Describe
  • Specifications
  • Application
  • Order Information
  • Documentation
  • Download
  • Ethernet and PoE connections both restrict cable distances to 100 meters between network ports. To overcome this distance limit, network installers can simply connect an PoE Extender in-line with the Cat-5e or Cat-6 calbe.



    With PoE Extender, PDs (such as IP Security Cameras, VoIP telephones, wireless access points) can be installed at greater distances than 100 meters from one another. By connecting PoE Extender for every extra 100 meters of cable, both Ethernet and PoE can be extended to 200 meters, 300 meters, or even greater distances, depending on PDs power required and power source.



    PoE Extender does not require any additional power supply and the connected PDs is fed by an single Ultra- PoE switch or mid-span, which simplifies installation. PoE Extender offers two Ethernet ports, which are both configured automatically for link speed, duplex and crossover and the full-rate network throughput is main-tained.



    Product Features:

    ● Compatible with IEEE802.3af and IEEE802.3at IEEE802.3bt

    ● Extends the range of PoE and Ethernet an additional 100 meters

    ● No additional power supply is required

    ● Automatically detects and protects PoE equipments from being damaged by incorrect installation

    ● Full-rate network throughout the whole extended distance

    ● Compact size, Rack-Mountable design

    ● Easy plug-and-play installation

    ● IP65 aluminum case

    ● Operating Ambient Temperature:-20 to 50℃

  • Item

    Description

    No. of channels

    4

    Pass Through Data Rates

    10/100 Mbps half/full duplex

    Power over Ethernet input

    Ultra POE 60W input

    Power over Ethernet Output

    Pin Assignment and Polarity:

    1/2 (-), 3/6 (+)

    Output Power: up to 25W per port

    Connectors

    Shielded RJ-45, EIA 568A and 568B

    Network cables

    Shielded category 5 (or higher)

    Mounting

    Wall of shelf

    Environment

    Outdoor IP30

    Environmental Conditions

    Operating Ambient Temperature:-40 to 75

    Operating Humidity:

    Maximum 90%, Non-condensing

    Storage Temperature:-40 to 75

    Storage Humidity:

    Maximum 95%, Non-condensing

    Regulatory Compliance

    IEEE 802.3af (PoE), IEEE 802.3at (PoE+) IEEE802.3bt( Ultra POE)

    RoHS Compliant, CE, FCC

    Electromagnetic

    FCC Part15, Class B

  • IPX104

    1 Ports 60W POE in 4 Ports Output extender
