Gigabit 8 port unmanaged industrial switch

Applied to rail transit, expressway, power station, pipe gallery project and wireless wiring project

Key words: switch

Messages
  • Describe
  • Specifications
  • Application
  • Order Information
  • Documentation
  • Download
  • IDS1608, a full Gigabit unmanaged industrial switches, have 8 gigabit copper ports.



    IP40 protection class, fanless design, available at extreme temperatures



    Stable operation within the scope of the industry can adapt to the harsh working environment. Redundant power input to ensure uninterrupted operation of the equipment.



    IDS1608 installation flexibility, more high reliability, security, to ensure that the key data transmission network.



    8 Gigabit copper ports



    Plug and play, MINI solid aluminum shell, easy to install



    Suppose broadcast storm function



    Wide voltage input, power failure alarm



    Support -40 ℃ cold start, 85 ℃ high temperature full load operation suitable for high temperature, high humidity, cold harsh environment applications

  • standard

    IEEE802.3 10BaseT

    IEEE802.3u 100BaseT / 100BaseFX

    IEEE802.3z 1000BaseX

    IEEE802.3ab 1000BaseT (X)

    IEEE802.3x Flow control



    interface

    Electric port: 8 10/100 / 1000BaseT (X)

    LED indicator: PWR power light, light port indicator

    Alarm output: current load 2A 30DC or 0.5A 125VAC



    power supply

    Input voltage: 12-36VDC dual redundant power input

    Reverse protection: support reverse

    Power connector: 5pin terminal block



    Mechanical properties

    Housing: IP40 protection class

    Size (W * H * D): 150 * 100 * 37MM

    Weight: 0.50KG

    Installation: rail installation, wall-mounted installation



    working environment

    Operating temperature: -40 ~ 85 ℃

    Storage temperature: -40 ~ 85 ℃

    Relative temperature: 5 ~ 95% (no cream)



    Industry Standard

    EMI: FCC Part 15 Subpart B Class A

    En55022 ClassA

    EMS:

    IEC (EN) 61000-4-2 (ESD), level 4

    IEC (EN) 61000-4-3 (RS), level 3

    IEC (EN) 61000-4-4 (EFT), level 4

    IEC (EN) 61000-4-5 (Surge), level 4

    IEC (EN) 61000-4-6 (CS), level 3

    IEC 61000-4-8

    IEC600068-2-27 Shock

    IEC600068-2-32 Freefall

    IEC600068-2-6 Vibration

    MTBF (mean time between failures): 100,000 hours

    Warranty period: 5 years
